 ...Tekniska data
|
 ...Specifications
|
| Motortyp |
JAP 1-cyl. OHV Double Port |
Engine typ |
JAP 1-cyl. OHV Double Port |
| Slagvolym |
344 cc |
Capacity |
344 cc |
| Borr x slag |
74 x 80 mm |
Bore x stroke |
74 x 80 mm |
| Förgasare |
Binks two lever or Amal |
Carburettor |
Binks two lever or Amal |
| Tändsystem |
ML magnet |
Ignition |
ML magneto |
| Smörjsystem |
Pilgrim mekanisk pump (Castrol R) |
Lubrcation |
Pilgrim mechanical pump (Castrol R) |
| Växellåda |
Burman 3-växlad (utväxling 5, 7.5 och 10.3) |
Gearbox |
Burman 3-speed (ratios 5, 7.5 och 10.3) |
| Transmission |
Kedja 5/8" x 1/4" |
Transmission |
Chain 5/8" x 1/4" |
| Bromsar |
fram: 5", bak: 6½" |
Brakes |
front: 5", rear: 6½" |
| Däck, fram & bak |
27 x 2,75" Dunlop TT Pattern Cords |
Tyres, front & rear |
27 x 2,75" Dunlop TT Pattern Cords |
| Bränsletank |
2 gallons (9 liter), lackad svart / guldrand |
Petrol tank |
2 gallons, painted black / gold |
| Oljetank |
2 pints (1,1 liter) |
Oil tank |
2 pints |
| Hjulbas |
53½" (136 cm) |
Wheelbase |
53½" |
| Ram |
HRD single loop, lackad svart |
Frame |
HRD single loop, painted black |
| Framgaffel |
Druid |
Front fork |
Druid |
| Stänkskärmar |
4", rund Sport-typ |
Mudguards |
4", round Sports-type |
| Toppfart |
80 Mph (129 km/t) |
Speed |
80 Mph |
| Pris |
80 Guineas (84 £) |
Price |
80 Guineas (84 £) |
|
