 ...Tekniska data
|
 ...Specifications
|
| Motortyp |
JAP 1-cyl. OHV Sports |
Engine typ |
JAP 1-cyl. OHV Sports |
| Slagvolym |
488 cc |
Capacity |
488 cc |
| Borr x slag |
85,5 x 85,0 mm |
Bore x stroke |
85,5 x 85,0 mm |
| Förgasare |
Binks two lever eller Amal |
Carburettor |
Binks two lever or Amal |
| Tändsystem |
ML magnet |
Ignition |
ML magneto |
| Smörjsystem |
Pilgrim mekanisk pump (Castrol R) |
Lubrcation |
Pilgrim mechanical pump (Castrol R) |
| Växellåda |
Burman 3-växlad (utväxling 4.64, 6.87 och 9.35) |
Gearbox |
Burman 3-speed (ratios 4.64, 6.87 and 9.35) |
| Transmission |
Kedja, primär: ½" x .305 |
Transmission |
Chain, primary: ½" x .305" |
|
Kedja, sekundär: 5/8" x 1/4" |
|
Chain, secondart: 5/8" x 1/4" |
| Bromsar |
fram: 5", bak: 6½" |
Brakes |
front: 5", rear: 6½" |
| Däck, fram & bak |
26 x 3,25" Dunlop TT Pattern Cords |
Tyres, front & rear |
26 x 3,25" Dunlop TT Pattern Cords |
| Oljetank |
2 pints (1,1 liter) |
Oil tank |
2 pints |
| Bränsletank |
2 gallons (9 liter), lackad svart / guldrand |
Petrol tank |
2 gallons, painted black / gold |
| Hjulbas |
53½" (136 cm) |
Wheelbase |
53½" |
| Ram |
HRD single loop, lackad svart |
Frame |
HRD single loop, painted black |
| Framgaffel |
Webb |
Front Fork |
Webb |
| Toppfart |
85 - 90 Mph (137 - 144 km/t) |
Speed |
85 - 90 Mph |
| Pris |
76 Guineas (79,80 £) |
Price |
76 Guineas (79,80 £) |
|
