 ...Tekniska data
|
 ...Specifications
|
| Motortyp |
Vincent Twin, OHV |
Engine typ |
Vincent Twin, OHV |
| Slagvolym |
998 cc |
Capacity |
998 cc |
| Borr x slag |
84 x 90 mm |
Bore x stroke |
84 x 90 mm |
| Kompression |
6,45 : 1 |
Compression ratio |
6,45 : 1 |
| Effekt |
45 Hk / 5300 rpm |
Power |
45 Hk / 5300 rpm |
| Förgasare |
Amal Monobloc 376 1 1/16" |
Carburettor |
Amal Monobloc 376 1 1/16" |
| Tändsystem |
Lucas brytare & spole |
Ignition |
Lucas Coil Ignition |
| Elsystem |
Lucas E3L generator, 6 volt 60 watt |
Electrics |
Lucas E3L generator, 6 volt 60 watt |
| Växellåda |
Vincent 4-växlad |
Gearbox |
Vincent 4-speed |
|
- Utväxling 3,5 4,16 5,64 och 9,1 |
|
- Ratios 3.5, 4.16, 5.64 and 9.1 |
| Koppling |
Vincent servo |
Clutch |
Vincent servo |
| Primärtrans. |
Triplex kedja 0,375" |
Primary Trans. |
Triplex chain 0,375" |
| Drivkedja |
5/8 x 3/8" |
Drive Chain |
5/8 x 3/8" |
| Bromsar |
Fram: dubbla 7", bak: enkel flänsad 7" |
Brakes |
Front: double 7" drums, rear: single ribbed 7" |
| Däck, fram & bak |
Fram: 3,50 x 19", bak: 4,00 x 18" |
Tyres |
Front: 3.50 x 19", rear: 4.00 x 18" |
| Bränsletank |
4 gallons (18,2 liter), lackad svart |
Petrol tank |
4 gallons, painted black |
| Oljetank |
5 pints (2,8 liter) |
Oil Tank |
5 pints |
| Hjulbas |
56½" (144 cm) |
Wheelbase |
56½" |
| Framgaffel |
Girdraulic |
Front Fork |
Girdraulic |
| Torrvikt |
460 lb (207 kg) |
Dry Weight |
460 lb |
| Toppfart |
110 MPH (177 km) |
Top speed |
110 MPH |
|
