 ...Tekniska data
|
 ...Specifications
|
| Motortyp |
Vincent 1-cyl. toppventil |
Engine typ |
Vincent 1-cyl. OHV |
| Slagvolym |
499 cc |
Capacity |
499 cc |
| Borr x slag |
84 x 90 mm |
Bore x stroke |
84 x 90 mm |
| Kompression |
8 : 1 |
Comp. ratio |
8 : 1 |
| Effekt BHP |
28 hk / 5.600 rpm |
Power BHP |
28 hp / 5.300 rpm |
| Förgasare |
Amal TT 1 5/32" |
Carburettor |
Amal TT 1 5/32" |
| Tändsystem / el |
Miller magnet-generator |
Ignition |
Miller mag-dynamo |
| Växellåda |
Burman 4-växlad. Utväxling 4,6 5,6 6,2 7,8 |
Gearbox |
Burman 4-speed. Ratios 4,6 5,6 6,2 7,8 |
| Transmission |
Primärkedja: 0,375" duplex |
Transmission |
Primary chain: 0,375" duplex |
|
Sekundärkedja: 5/8" x 3/8" |
|
Secondary chain: 5/8" x 3/8" |
| Bromsar |
7" duo fram & bak |
Brakes |
7" duo front and rear |
| Däck |
Avon, fram: 26" x 3,0", bak: 26" x 3,25" |
Tyres |
Avon, front: 26" x 3,0", rear: 26" x 3,25" |
| Bränsletank |
3 1/4 gallons (14,75 liter), lackad svart |
Petrol tank |
3 1/4 gallons, painted black |
| Oljetank |
3½ pints (2 liter) |
Oil tank |
3½ pints |
| Hjulbas |
55" (140 cm) |
Wheelbase |
55" |
| Ram |
Vincent Diamond fjädrad, lackad svart |
Frame |
Vincent Diamond, sprung, painted black |
| Skärmar |
5" stål |
Mudguards |
5" steel |
| Framgaffel |
Brampton |
Front fork |
Brampton |
| Toppfart |
90 - 95 Mph (145 - 153 Kmh) |
Top Speed |
90 - 95 Mph |
|
