 ...Tekniska data
|
 ...Specifications
|
| Motortyp |
Vincent V-twin, OHV |
Engine typ |
Vincent V-twin, OHV |
| Slagvolym |
998 cc |
Capacity |
998 cc |
| Borr x slag |
84 x 90 mm |
Bore x stroke |
84 x 90 mm |
| Effekt |
70 Hk / 5600 rpm |
Power |
70 Hk / 5600 rpm |
| Förgasare |
Amal 32 mm 10TT9 |
Carburettor |
Amal 32 mm 10TT9 |
| Tändsystem |
Lucas KVF TT Magnet |
Ignition |
Lucas KVF TT Magneto |
| Växellåda |
Vincent 4-växlad |
Gearbox |
Vincent 4-speed |
|
- Utväxling 3.25, 3.89, 5.26 och 6.77 |
|
- Ratios 3.25, 3.89, 5.26 and 6.77 |
| Koppling |
Vincent servo |
Clutch |
Vinent Servo |
| Primärtrans. |
Triplexkedja 0,375" |
Primary Trans. |
Triplex Chain 0,375" |
| Drivkedja |
5/8 x 1/4" |
Drive Chain |
5/8 x 1/4" |
| Bromsar |
Dubbla 7" flänsade trummor fram & bak |
Brakes |
Double 7" ribbed drums front & rear |
| Däck, fram & bak |
Fram. 3,00 x 21", bak: 3,50 x 20" |
Tyres |
Front. 3,00 x 21", rear: 3,50 x 20" |
| Bränsletank |
3 3/8 gallons (17 liter), lackad svart / guldrand |
Petrol tank |
3 3/8 gallons, painted black / gold |
| Oljetank |
6 pints (3,4 liter) |
Oil Tank |
6 pints |
| Hjulbas |
56½" (146 cm) |
Wheelbase |
56½" |
| Framgaffel |
Girdraulic |
Front Fork |
Girdraulic |
| Torrvikt |
380 lb (171 kg) |
Dry Weight |
380 lb |
| Toppfart |
150 MPH (241 km) |
Top speed |
150 MPH |
|
