 ...Tekniska data
|
 ...Specifications
|
| Motortyp |
Vincent Twin, OHV |
Engine typ |
Vincent Twin, OHV |
| Slagvolym |
998 cc |
Capacity |
998 cc |
| Borr x slag |
84 x 90 mm |
Bore x stroke |
84 x 90 mm |
| Kompression |
7,3 : 1 |
Compression ratio |
7,3 : 1 |
| Effekt |
55 Hk / 5700 rpm |
Power |
55 Hk / 5700 rpm |
| Förgasare |
Amal 1 1/8" |
Carburettor |
Amal 1 1/8" |
| Tändsystem |
Lucas KVF GM1 magnet |
Ignition |
Lucas KVF GM1 Magneto |
| Elsystem |
Miller generator, 6 volt 50 watt |
Electrics |
Miller generator, 6 volt 50 watt |
| Växellåda |
Vincent 4-växlad |
Gearbox |
Vincent 4-speed |
|
- Utväxling 3,5 4,16 5,64 och 7,27 (ändrades under 1951 till 9,1) |
|
- Ratios 3.5, 4.16, 5.64 and 7.27 (replaced during 1950 to 9.1) |
| Koppling |
Vincent servo |
Clutch |
Vincent servo |
| Primärtrans. |
Triplex kedja 0,375" |
Primary Trans. |
Triplex chain 0,375" |
| Drivkedja |
5/8 x 3/8" |
Drive Chain |
5/8 x 3/8" |
| Bromsar |
Dubbla 7" flänsade fram & bak |
Brakes |
Double 7" ribbed drums front & rear |
| Däck, fram & bak |
Fram: 3,00 x 20", bak: 3,50 x 19" |
Tyres |
Front: 3,00 x 20", rear: 3,50 x 19" |
| Bränsletank |
3½ gallons (15,9 liter), lackad svart / guldrand |
Petrol tank |
3½ gallons, painted black / gold |
| Oljetank |
6 pints (3,4 liter) |
Oil Tank |
6 pints |
| Hjulbas |
56½" (144 cm) |
Wheelbase |
56½" |
| Framgaffel |
Girdraulic |
Front Fork |
Girdraulic |
| Torrvikt |
458 lb (206 kg) |
Dry Weight |
458 lb |
| Toppfart |
125 MPH (201 km) |
Top speed |
125 MPH |
|
