 ...Tekniska data
|
 ...Specifications
|
| Motortyp |
JAP 1-cyl. OHV dubbelport |
Engine typ |
JAP 1-cyl. OHV double port |
| Slagvolym |
490 cc |
Capacity |
490 cc |
| Borr x slag |
85,7 x 85,0 mm |
Bore x stroke |
85,7 x 85,0 mm |
| Förgasare |
Amal two lever |
Carburettor |
Amal two lever |
| Tändsystem |
ML magnet |
Ignition |
ML magneto |
| Smörjsystem |
Best and Lloyd mekanisk pump |
Lubrcation |
Best and Lloyd mechanical pump |
| Växellåda |
Burman 3-växlad |
Gearbox |
Burman 3-speed |
| Transmission |
Kedja 1/2" x 5/16" |
Transmission |
Chain 1/2" x 5/16" |
| Bromsar |
7" fram & bak |
Brakes |
7" front and rear |
| Däck, fram & bak |
26" x 3,25" Clincher Cords |
Tyres, front & rear |
26" x 3,25" Clincher Cords |
| Bränsletank |
2½ gallons (11,3 liter), lackad svart |
Petrol tank |
2½ gallons, painted black |
| Oljetank |
7½ pints (4,25 liter) |
Oil tank |
7½ pints |
| Hjulbas |
56" (142 cm) |
Wheelbase |
56" |
| Ram |
Vincent triangulär fjädrad, lackad svart |
Frame |
Vincent Triangulated, sprung, painted black |
| Framgaffel |
Druid |
Front fork |
Druid |
| Stänkskärmar |
5", D-typ |
Mudguards |
5", D-type |
| Toppfart |
75 - 80 Mph (120 - 128 Km/t) |
Speed |
75 - 80 Mph |
| Pris |
75 £ |
Price |
75 £ |
|
