 ...Tekniska data
|
 ...Specifications
|
| Motortyp |
JAP 1-cyl. OHV Double Port |
Engine typ |
JAP 1-cyl. OHV Double Port |
| Slagvolym |
488 cc |
Capacity |
488 cc |
| Borr x slag |
85,5 x 85,0 mm |
Bore x stroke |
85,5 x 85,0 mm |
| Förgasare |
Binks two lever eller Amac |
Carburettor |
Binks two lever or Amac |
| Tändsystem |
ML magnet |
Ignition |
ML magneto |
| Smörjsystem |
Pilgrim mekanisk pump (Castrol R) |
Lubrcation |
Pilgrim mechanical pump (Castrol R) |
| Växellåda |
Burman 3-växlad (utväxling 4.5, 6.55 och 9) |
Gearbox |
Burman 3-speed (ratios 4.5, 6.55 and 9) |
| Transmission |
Kedja 5/8" x 1/4" |
Transmission |
Chain 5/8" x 1/4" |
| Bromsar |
fram: 6", bak: 7" ribbad |
Brakes |
front: 6", rear: 7" ribbed |
| Däck, fram & bak |
700 x 80 mm Dunlop TT pattern cords |
Tyres, front & rear |
700 x 80 mm Dunlop TT pattern cords |
| Bränsletank |
2 gallons 3 pints (10,8 liter), svart / guldrand |
Petrol tank |
2 gallons 3 pints, painted black / gold |
| Hjulbas |
53½" (136 cm) |
Wheelbase |
53½" |
| Ram |
HRD single loop, lackad svart |
Frame |
HRD single loop, painted black |
| Framgaffel |
Webb eller Druid |
Front fork |
Webb or Druid |
| Stänkskärmar |
5", D-typ |
Mudguards |
5", D-type |
| Toppfart |
100 Mph (160 km/t) |
Speed |
100 Mph |
| Pris |
98 Guineas (102,90 £) |
Price |
98 Guineas (102,90 £) |
|
