 ...Tekniska data
|
 ...Specifications
|
| Motortyp |
JAP 1-cyl. OHV Double Port |
Engine typ |
JAP 1-cyl. OHV Double Port |
| Slagvolym |
488 cc |
Capacity |
488 cc |
| Borr x slag |
85,5 x 85,0 mm |
Bore x stroke |
85,5 x 85,0 mm |
| Förgasare |
Binks two lever eller Amac |
Carburettor |
Binks two lever or Amac |
| Tändsystem |
ML fyrkantig Racing magnet |
Ignition |
ML square type Racing magneto |
| Smörjsystem |
Pilgrim mekanisk pump (Castrol R) |
Lubrcation |
Pilgrim mechanical pump (Castrol R) |
| Växellåda |
Burman 3-växlad (utväxling 4.5, 6.7 och 9) |
Gearbox |
Burman 3-speed (ratios 4.5, 6.7 and 9) |
| Primärtransmission |
Kedja ½" x 0,305" |
Primary transmission |
Chain ½" x 0,305" |
| Sluttransmission |
Kedja 5/8" x 3/8" |
Secondary transmission |
Chain 5/8" x 3/8" |
| Bromsar |
fram: 7", bak: 7" ribbad |
Brakes |
front: 7", rear: 7" ribbed |
| Däck, fram & bak |
26 x 25" Dunlop TT pattern cords |
Tyres, front & rear |
26 x 25" Dunlop TT pattern cords |
| Bränsletank |
3 gallons (13,6 liter), lackad svart / guldrand |
Petrol tank |
3 gallons, painted black / gold |
| Oljetank |
3½ pints (2 liter) |
Oil tank |
3½ pints |
| Hjulbas |
53½" (136 cm) |
Wheelbase |
53½" |
| Ram |
HRD duplex, lackad svart |
Frame |
HRD duplex, painted black |
| Framgaffel |
Webb eller Druid |
Front fork |
Webb or Druid |
| Stänkskärmar |
5½", D-typ |
Mudguards |
5½", D-type |
| Toppfart |
90 till 100 Mph (144 till 160 km/t) |
Speed |
90 to 100 Mph |
| Pris |
98 Guineas |
Price |
98 Guineas |
|
