 ...Tekniska data
|
 ...Specifications
|
| Motortyp |
JAP 1-cyl. OHV dubbelport Standard |
Engine typ |
JAP 1-cyl. OHV double port Standard |
| Slagvolym |
344 cc |
Capacity |
344 cc |
| Borr x slag |
74 x 80 mm |
Bore x stroke |
74 x 80 mm |
| Förgasare |
Amal two lever |
Carburettor |
Amal two lever |
| Tändsystem |
ML magnet |
Ignition |
ML magneto |
| Växellåda |
Burman 3-växlad |
Gearbox |
Burman 3-speed |
| Transmission |
Kedja, primär 1/2" x 5/16" |
Transmission |
Primary chain 1/2" x 5/16" |
|
Kedja, sekundär 5/8" x 3/8" |
|
Secondary chain 5/8" x 3/8" |
| Bromsar |
7" fram & bak |
Brakes |
7" front and rear |
| Däck, fram & bak |
26" x 3,25" Clincher Cords |
Tyres, front & rear |
26" x 3,25" Clincher Cords |
| Bränsletank |
2½ gallons (11,3 liter), lackad svart |
Petrol tank |
2½ gallons, painted black |
| Oljetank |
3 pints (1,7 liter) |
Oil tank |
3 pints |
| Hjulbas |
56" (142 cm) |
Wheelbase |
56" |
| Ram |
Vincent triangulär fjädrad, lackad svart |
Frame |
Vincent Triangulated, sprung, painted black |
| Framgaffel |
Druid Racing |
Front fork |
Druid Racing |
| Stänkskärmar |
5", runda |
Mudguards |
5", domed |
| Toppfart |
65 Mph (104 Km/t) |
Speed |
65 Mph |
| Pris |
£ 64 |
Price |
£ 64 |
|
