 ...Tekniska data
|
 ...Specifications
|
| Motortyp |
JAP 1-cyl. Sports Sidventil |
Engine typ |
JAP 1-cyl. Sports Sidevalve |
| Slagvolym |
597 cc |
Capacity |
597 cc |
| Borr x slag |
85,5 x 104,0 mm |
Bore x stroke |
85,5 x 104,0 mm |
| Förgasare |
Binks two lever eller Amal |
Carburettor |
Binks two lever or Amal |
| Tändsystem |
ML magnet |
Ignition |
ML magneto |
| Smörjsystem |
Pilgrim mekanisk pump (Castrol XL) |
Lubrcation |
Pilgrim mechanical pump (Castrol XL) |
| Växellåda |
Burman 3-växlad, utväxling 5.1, 8.1 och 14.2 |
Gearbox |
Burman 3-speed, ratios 5.1, 8.1 and 14.2 |
| Transmission |
Kedja primär, ½ x .305" |
Transmission |
Primary chain ½ x .305" |
|
Kedja sekundär 5/8" x 1/4" |
|
Secondary chain 5/8" x 1/4" |
| Bromsar |
fram 6" och bak 7" flänsad |
Brakes |
front 6" and rear 7" ribbed |
| Däck, fram & bak |
26 x 3.25" Dunlop Cords |
Tyres, front & rear |
26 x 3.25" Dunlop Cords |
| Bränsletank |
2 gallons (9 liter), lackad svart / guldrand |
Petrol tank |
2 gallons, painted black / gold |
| Oljetank |
2 pints 1,1 liter) |
Oil tank |
2 pints |
| Hjulbas |
53½" (136 cm) |
Wheelbase |
53½" |
| Ram |
HRD single loop, lackad svart |
Frame |
HRD single loop, painted black |
| Framgaffel |
Webb eller Druid |
Front fork |
Webb or Druid |
| Stänkskärmar |
5½", D-typ ( välvd framskärm) |
Mudguards |
5½", D-type (front mudguard valanced) |
| Pris |
72 Guineas (75,6 £) |
Price |
72 Guineas (75,6 £) |
|
