 ...Tekniska data
|
 ...Specifications
|
| Motortyp |
JAP 1-cyl. OHV Standard |
Engine typ |
JAP 1-cyl. OHV Standard |
| Slagvolym |
490 cc |
Capacity |
490 cc |
| Borr x slag |
85,7 x 85,0 mm |
Bore x stroke |
85,7 x 85,0 mm |
| Förgasare |
Binks two lever eller Amal |
Carburettor |
Binks two lever or Amal |
| Tändsystem |
ML magnet |
Ignition |
ML magneto |
| Smörjsystem |
Pilgrim mekanisk pump (Castrol XL) |
Lubrcation |
Pilgrim mechanical pump (Castrol XL) |
| Växellåda |
Burman 3-växlad, utväxling 4.64, 6.87 och 9.35 |
Gearbox |
Burman 3-speed, ratios 4.64, 6.87 and 9.35 |
| Transmission |
Primärkedja ½ x .305" |
Transmission |
Primary chain ½ x .305" |
|
Sekundärkedja 5/8" x 1/4" |
|
Secondary chain 5/8" x 1/4" |
| Bromsar |
fram: 6" bak: 7" |
Brakes |
front: 6" rear: 7" |
| Däck, fram & bak |
26 x 3,25" Dunlop TT Pattern Cords |
Tyres, front & rear |
26 x 3,25" Dunlop TT Pattern Cords |
| Bränsletank |
2 gallons (9 liter), lackad svart / guldrand |
Petrol tank |
2 gallons, painted black / gold |
| Oljetank |
2 pints (1,1 liter) |
Oil tank: |
2 pints |
| Hjulbas |
53½" (136 cm) |
Wheelbase |
53½" |
| Ram |
HRD single loop, lackad svart |
Frame |
HRD single loop, painted black |
| Framgaffel |
Webb |
Front fork |
Webb |
| Toppfart |
75 Mph (120 km/t) |
Top speed |
75 Mph |
| Pris |
63 Guineas (66,15 £) |
Price |
63 Guineas (66,15 £) |
|
