 ...Tekniska data
|
 ...Specifications
|
| Motortyp |
Vincent 1-cyl. toppventil |
Engine typ |
Vincent 1-cyl. OHV |
| Slagvolym |
499 cc |
Capacity |
499 cc |
| Borr x slag |
84 x 90 mm |
Bore x stroke |
84 x 90 mm |
| Kompression |
7,3 : 1 |
Comp. ratio |
7,3 : 1 |
| Effekt BHP |
26 hk / 5.600 rpm |
Power BHP |
26 hp / 5.600 rpm |
| Förgasare |
Amal 1 1/8" |
Carburettor |
Amal 1 1/8" |
| Tändsystem / el |
BTH magnet-generator |
Ignition |
BTH mag-dynamo |
| Växellåda |
Burman 4-växlad. Utväxling 4,6 5,8 7,2 12,4 |
Gearbox |
Burman 4-speed. Ratios 4,6 5,8 7,2 12,4 |
| Transmission |
Primärkedja: 0,375" duplex |
Transmission |
Primary chain: 0,375" duplex |
|
Sekundärkedja: 5/8" x 3/8" |
|
Secondary chain: 5/8" x 3/8" |
| Bromsar |
7" duo fram & bak |
Brakes |
7" duo front and rear |
| Däck |
Avon, fram: 26" x 3,0", bak: 26" x 3,25" |
Tyres |
Avon, front: 26" x 3,0", rear: 26" x 3,25" |
| Bränsletank |
3 1/4 gallons (14,75 liter), lackad svart |
Petrol tank |
3 1/4 gallons, painted black |
| Oljetank |
3½ pints (2 liter) |
Oil tank |
3½ pints |
| Hjulbas |
55" (140 cm) |
Wheelbase |
55" |
| Ram |
Vincent Diamond fjädrad, lackad svart |
Frame |
Vincent Diamond, sprung, painted black |
| Skärmar |
5" stål |
Mudguards |
5" steel |
| Framgaffel |
Brampton |
Front fork |
Brampton |
| Vikt |
385 lb (173 Kg) |
Weight |
385 lb |
| Toppfart |
85 - 90 Mph (137 - 145 Kmh) |
Top Speed |
85 - 90 Mph |
| Pris |
£ 86 |
Price |
£ 86 |
|
