 ...Tekniska data
|
 ...Specifications
|
| Motortyp |
Vincent 1-cyl, OHV |
Engine typ |
Vincent 1-cyl, OHV |
| Slagvolym |
499 cc |
Capacity |
499 cc |
| Borr x slag |
84 x 90 mm |
Bore x stroke |
84 x 90 mm |
| Kompression |
6,8 : 1 |
Comp. ratio |
6.8 : 1 |
| Effekt |
28 Hk / 5800 rpm |
Power |
28 Hk / 5800 rpm |
| Förgasare |
Amal 229 F/1DV |
Carburettor |
Amal 229 F/1DV |
| Tändsystem |
Lucas K1F GM2 magnet |
Ignition |
Lucas K1F HM2 Magneto |
| Elsystem |
Miller generator, 6 volt 50 watt |
Electrics |
Miller generator, 6 volt 50 watt |
| Växellåda |
Burman 4-växlad |
Gearbox |
Burmant 4-speed |
|
- Utväxling 4,64 5,94 8,17 och 12,4 |
|
- Ratios 4.64, 5.94, 8.176 and 12.4 |
| Koppling |
Burman flerskivig |
Clutch |
Burman multiplate |
| Primärtrans. |
Kedja ½" x 5/16" |
Primary Trans. |
Chain ½" x 5/16" |
| Drivkedja |
5/8 x 3/8" |
Drive Chain |
5/8 x 3/8" |
| Bromsar |
Dubbla 7" trummor fram & bak |
Brakes |
Double 7" drums front & rear |
| Däck, fram & bak |
Fram: 3,00 x 20", bak: 3,50 x 19" |
Tyres |
Front: 3,00 x 20", rear: 3,50 x 19" |
| Bränsletank |
3½ gallons (15,9 liter), lackad svart / guldrand |
Petrol tank |
3½ gallons, painted black / gold |
| Oljetank |
6 pints (3,4 liter) |
Oil Tank |
6 pints |
| Hjulbas |
55 3/4" (142 cm) |
Wheelbase |
55 3/4" |
| Framgaffel |
Girdraulic |
Front Fork |
Girdraulic |
| Torrvikt |
390 lb (175 kg) |
Dry Weight |
380 lb |
| Toppfart |
90 MPH (145 km) |
Top speed |
90 MPH |
| Pris |
£ 273 (1949, inkl skatt £ 58) |
Price |
£ 273 (1949, including £ 58 tax) |
|
