 ...Tekniska data
|
 ...Specifications
|
| Motortyp |
Vincent 2-cyl. toppventil |
Engine typ |
Vincent 2-cyl. OHV |
| Slagvolym |
998 cc |
Capacity |
998 cc |
| Borr x slag |
84 x 90 mm |
Bore x stroke |
84 x 90 mm |
| Kompression |
6,45 : 1 |
Comp. ratio |
6,45 : 1 |
| Effekt BHP |
45 hk / 5.300 rpm |
Power BHP |
45 hp / 5.300 rpm |
| Förgasare |
Amal 276, 1 1/16" |
Carburettor |
Amal 276, 1 1/16" |
| Tändsystem |
Lucas KVF GM1 magnet |
Ignition |
Lucas KVF GM1 magneto |
| Elsystem |
Miller generator, 6 V 50 W |
Electrics |
Miller generator, 6 V 50 W |
| Växellåda |
Vincent 4-växlad. Utväxling 3,5 4,16 5,64 9,1 |
Gearbox |
Vincent 4-speed. Ratios 3,5 4,16 5,64 9,1 |
| Transmission |
Primärkedja: 0,375" triplex |
Transmission |
Primary chain: 0,375" triplex |
|
Sekundärkedja: 5/8" x 3/8" |
|
Secondary chain: 5/8" x 3/8" |
| Bromsar |
7" duo fram & bak |
Brakes |
7" duo front and rear |
| Däck |
fram: 20" x 3,0", bak: 19" x 3,25" |
Tyres |
front: 20" x 3,0", rear:18" x 3,25" |
| Bränsletank |
3½ gallons (15,9 liter), lackad svart |
Petrol tank |
3½ gallons, painted black |
| Oljetank |
6 pints (3,4 liter) |
Oil tank |
6 pints |
| Hjulbas |
56½" (144 cm) |
Wheelbase |
56½" |
| Ram |
Vincent Diamond fjädrad, lackad svart |
Frame |
Vincent Diamond, sprung, painted black |
| Framgaffel |
Brampton |
Front fork |
Brampton |
| Vikt |
455 lb (205 Kg) |
Weight |
455 lb |
| Toppfart |
110 Mph (177 Kmh) |
Top Speed |
110 Mph |
| Pris |
> £ 300 (1948 inkl skatt £ 75) |
Price |
> £ 300 (including tax £ 75) |
|
